Abstract

Our Public Address (PA) and Intercom(IC) system DVS-21 now is available in a small system

configuration. This “Smart DVS-21" is suited outstandingly for small plants with only a few

PA / IC targets.

All features of proven and reliable DVS-21 technology can be used in this system,

also expansion to the bigger standard 19" backplane is possible.

Sowhatyouwillgetisarealflexibleprofessionalintercomsystem.Thiscomestoavery

competitivepriceandthuscansavefirstinvestmentsofthecustomer.

Configurations

ConfigurationExample1:MixedPA /Intercomsolution

Basedona3HU/42MUshelfreadyformountingintostandard19”halfframes,various

customizedconfigurationsareavailable.

Justtogiveanimpressionofourdesignidea,threeconfigurationexamplesshallbe

highlightedinmoredetail.:

(seepictureabove)

oneDC/DCpowersupplymodule incl.2xdrycontactsfore.g.loudspeaker

zonesplitting).

oneprocessormodule forPublic AddressusingIP /ISDN/E1

(incl.speechstorageasanoption)

oneanalogaudiointerfacemodule forswitchingonupto4callstations

in4-wiretechnology.

Twoamplifiermodules (100W/100V)forPublic Address

AnexternalDC/DC-Converter48VDC/10A isrequired.

SV01(

HCPU

4NSA

V100

DVS-21

CompactPublic Address/Intercom-System

in19”halfrack

SmartDVS-21

AllrightsandtechnicalmodificationsreservedV1.0

Alfredstrasse157

D-45131Essen

www.procom-communication.de

Tel.: +49(0)201860670-90

Fax.:+49(0)201860670-98

[email protected]

Deutschland/Germany

ProCom

ProfessionalCommunication

&ServiceGmbH

1 2

SmartDVS-21 1
